CARAT Anthracite 8023

Facade panels colored throughout.

The horizontal Modula structure has a fine architectonic rhythm. The slim panels, available in two different lengths, are installed as lapped coverings and can be arranged both with continuous and with offset vertical joints. A large number of different surfaces and colors enable numerous additional design variants.
Whether monochrome or multicolored, equal or varying format lengths, with continuous or offset joints – Modula provides immense scope for individual combinations.

mtex_117057, Fiber cement, Facade slate, Architektur, CAD, Textur, Tiles, kostenlos, free, Fiber cement, Swisspearl Schweiz AG

CARAT Anthracite 8023

Facade panels colored throughout.

The horizontal Modula structure has a fine architectonic rhythm. The slim panels, available in two different lengths, are installed as lapped coverings and can be arranged both with continuous and with offset vertical joints. A large number of different surfaces and colors enable numerous additional design variants.
Whether monochrome or multicolored, equal or varying format lengths, with continuous or offset joints – Modula provides immense scope for individual combinations.

Material information & characteristic values

Material NameCARAT Anthracite 8023
ManufacturerSwisspearl Schweiz AG
Product LineMODULA 2000x300x8
mtextur ID117057
TypeFiber cement / Facade slate
eBKPE 2.3 Facade cladding / E 2.3 Fassadenbekleidung / E 2.4 Facade systems / E 2.4 Fassadensystem
IFCIfcCovering / IfcCurtainWall
Area of application (mtextur Classic)Outside / Wall / Facade
Delivery zonesCH / DE / AT / CA / US / LI / SI
Material InfoFacade panels colored throughout.
max. Length / FormatLength = 2500 mm / Width = 300 mm / Thickness = 8 mm
min. FormatLength = 1500 mm / Width = 300 mm / Thickness = 8 mm
